Web Tools User’s Guide 3-31
Fabric View
3
WWN Config
Use the WWN Config tab to specify which zones comprise a WWN Zone Configuration file. The
WWN Config tab is shown in Figure 3-17.
Figure 3-17 WWN Config tab of the WWN Level Zoning menu
Following is a description of the fields on the WWN Config tab.
OK Select OK to the changes to the switch and exit the window.
Apply Click to apply all changes made including changes made on
other tabs in the view. Changes cannot be cancelled once they
are applied.
Close Click to exit the window without making any changes to the
switch.
Clr All Click to clear all Aliases, Zones, Configs, FA Zones locally on
the client.
Cfg Name Select to modify an existing WWN configuration name to be
modified.
Create Cfg Click to create a new WWN configuration.
Delete Cfg Click to delete a WWN configuration.
Rename Cfg Click to rename a WWN configuration.
