Wwn fabric assist – HP Surestore 6164 Switch User Manual
Page 51
Web Tools User’s Guide
3-29
Fabric View
3
WWN Fabric Assist
Use the WWN Fabric Assist tab to create and manage WWN Fabric Assists. A QuickLoop license
is required to use this tab. The WWN Fabric Assist tab is shown in Figure 3-17.
Figure 3-16 WWN Fabric Assist tab of the WWN Level Zoning Menu
Remove Mem
Click to remove a member from the QuickLoop member list when
selected.
Ref Zone
Click to refresh the local zoning data base copied from the switch.
This button automatically flashes red/gray if the fabric zoning data is
changed by another client.
A/D WWN
Click to add or delete a WWN to or from all the aliases, zones
defined.
Rpl WWN
Click to replace WWN with another one in all aliases, zones defined.
OK
Click to apply the changes to the switch and exit the switch.
Apply
Click to apply the changes to the switch.
Close
Click to exit the window without making any changes to the switch.
