Web Tools User’s Guide
4-37
Switch View
4
4.
Select the ALPA number that you want to graph by using one of the following methods:
•
Type the ALPA number in the Enter /drag SID Numbers window.
•
Drag the ALPA “file” from the Port Selection window to the Enter/drag ALPA Number
window.
5.
Select OK.
An ALPA Error graph will be displayed.
An example of an ALPA Error graph, displaying CRC errors for a given port and a given ALPA, is
shown in Figure 4-42.
Figure 4-42 ALPA Error Graph Example
Additional Options
The graphs available in the Performance Monitor feature provide additional options by using the
following methods:
•
Right-clicking on a graph
•
Tools Tips
These options are available by rolling over a graph with your mouse pointer
Right-Click Options
Each graph contains a variety of options that are available by pointing to a graph and right-clicking
your mouse.
