3-8 Web Tools User’s Guide
Fabric View
3
Following is a description of the fields in the Fabric Topology View.
Name Server Table View
The Name Server Table View provides the name server entries listed in the Simple Name Server
database. This includes all name server entries for the fabric, not only those that are local to the
local domain. Each row in the table represents a different device.
To access Name Server Table View:
1. Launch Web Tools, displaying Fabric View.
2. Select the Name Server Table View
For more information, see Button and Icons that appear in Fabric View on page 3-3.
The Name Server window displays, as shown in Name Server Table View on page 3-9.
View Fabric Topology from
Switch [switch name]: Lists the switch in the domain that is assumed to be the local
domain.
There are a total of [n]
domains in the fabric. The number of domains in the fabric.
Local domain ID: A number that uniquely identifies the local switch within the
fabric, and the name of the switch.
Domain ID: (may be
more than one) A number that uniquely identifies the switch within the
fabric, and the name of the switch.
Active Paths: This line is followed by information about each destination
domain, including information about each of the paths
between that domain and the local domain.
Destination Domain ID: The ID of the destination domain that is described in the
lines following the ID. This information and the two lines
following it display for each destination domain in the
fabric.
Destination’s
Worldwide Name: The WWN of the destination domain.
Number of Paths: The number of active paths between the destination domain
and the local domain.
