3-16 Web Tools User’s Guide
Fabric View
3
Add Mem Select to add the member selected in the Member Selection List to the
Zone Members list. If an entire switch is selected, all ports on the switch
are added to the zone. You can also select individual ports. To add a device
WWN, select either a node WWN (folder icon) or port WWN (blue circle
icon) from the WWNs sub-tree. To add an alias to the zone, select it from
the Aliases sub-tree (the alias must already exist).
Remove Mem Select to remove the selected member from the Zone name Members list.
[Zone name]
Members This field lists members of the zone selected in the Zone Name field. The
name of this list depends on the name of the selected zone. If no zone is
selected, the name displays as “null Members”.
Ref Zone Click to refresh the local zoning data base copied from the switch. This
button automatically flashes red/gray if the fabric zoning data is changed
by another client.
A/D WWN Click to add or delete a WWN to or from all the Aliases, Zones defined.
Rpl WWN Click to replace a WWN with another one in all Aliases, Zones defined.
OK Applies the changes to the switch and exits the frame.
Apply Click to apply all changes made since the Zone Administration View was
opened, including changes made on other tabs in the view. Changes cannot
be cancelled once they are applied.
Close Click to exit the window without making any changes to the switch.
Clr All Click to clear all Aliases, Zones, Configs locally on the switch.
