3-30 Web Tools User’s Guide
Fabric View
3
Following is a description of the fields on the WWN Fabric Assist tab.
FA Name Select an existing WWN Fabric Assist name to modify.
Create FA Click to create a new WWN Fabric Assist. A dialog displays.
Enter the name of the new WWN Fabric Assist. All names
must be unique and contain no spaces.
Delete FA Click to delete the WWN Fabric Assist selected in the FA
Name field. Deleting a WWN Fabric Assist automatically
removes it from all aliases, zones, and zone configurations,
including the associated AL_PAs.
Rename FA Click to edit the name of the WWN Fabric Assist selected in
the FA Name field.
Member Selection List This field displays a list of members available to add to the
WWN Fabric Assist.
Add FA Host Click to add the selected item as a host to the WWN Fabric
Assist name list. Only a domain port or a WWN can be added
as a host.
Add Mem Click to add the member selected in the Member Selection List
to the WWN Fabric Assist name list.
Remove Mem Click to remove the selected member from the WWN Fabric
Assist name list.
Search Mem Click to search for a Switch name, WWN, Alias, Zone,
QuickLoop, FA Zone in the Member Selection List based on
the type of objects displayed in that list.
[WWN Fabric Assist name]
FA Members A list of the members that belong to the WWN Fabric Assist
currently selected in the FA Name field. The name of this list
depends on the name of the WWN Fabric Assist selected. If no
WWN Fabric Assist is selected, the name displays as “null
Members”.
Ref Zone Click to refresh the local zoning data base copy from the
switch. This button would automatically flash red/gray if the
fabric zoning data is changed by another client.
Add WWN Click to add a WWN that is not currently part of the Fabric.
Add WWN Host Click to add a WWN Host that is not currently part of the
Fabric.
A/D WWN Click to add/delete a WWN to/from all the Aliases, Zones, FA
Zones defined.
Rpl WWN Click to replace a WWN with another one in all Aliases, Zones,
FA Zones defined.
