Web Tools User’s Guide 3-15
Fabric View
3
Port Zone Tab
Use the Port Zone tab to specify which ports on a switch are to be in the selected zone and to create
and manage zones. A zone can have one or multiple members, and can include switches, ports,
WWNs, aliases, and QuickLoop AL_PAs. The Port Zone tab
is shown in Figure 3-8.
Figure 3-8 The Port Zone tab of the Switch/Port Level Zoning menu
Following is a description of the fields on the Port Zone tab.
Zone Name To modify an existing zone, select a zone name.
Create Zone Select to create a new zone. A dialog displays in which you can enter the
name of the new zone. All names must be unique and contain no spaces.
Delete Zone Select to delete the zone selected in the Zone Name field. Deleting a zone
automatically removes it from all zone configurations.
Rename Zone Select to edit the name of the zone selected in the Zone Name field. A
dialog displays in which you can edit the name of the zone.
Search Mem Select to search the list of potential zone members.
Member Selection
List A list of potential zone members, including switches, ports, WWNs,
aliases, and QuickLoop AL_PAs, and Fabric Assists.
