4-6 Web Tools User’s Guide
Switch View
4
Loop Diagnostics Dialog Box
The Loop Diagnostics Dialog Box dialog appears when you click DIAG on the Loop tab of the
Port Information View. You can use the Loop Diagnostics option to identify faulty devices on a
loop. The Loop Diagnostics Dialog Box is shown in Figure 3-33.
Figure 4-3 Loop Diagnostics Dialog Box
Following is a description of the fields in the Loop Diagnostics dialog box:
LIP Dialog Box
Use the LIP (Loop Initialization Process) option to initialize a loop port. To access this option, click
LIP on the Loop tab of the Port Information View. The LIP Dialog Box is shown in Figure 3-34.
Figure 4-4 LIP Dialog Box
Following is a description of the fields in the LIP dialog box:
Start Click to start the Loop Diagnostics on the specified port.
Stop Click to stop (abort) Loop Diagnostics on the specified port.
Close Click to close the Loop Diagnostics function.
Apply Click to initialize a loop port.
Close Click to close the LIP dialog box.
