HP Surestore 6164 Switch - Manual (Page 133)

Web Tools User’s Guide 4-61
Switch View
4
Destination Displays the destination domain ID for the “comma-separated”
participating static routes for a particular inport. The destination
domain IDs match the outports in the cell.
Out Port Enter the Out port. It should be within the range of ports that are
available for static routes for the current domain. More than one out
port can be used for any In port with a different domain id. Each
domain id requires an out port.
OK Click to save the changes made to the tab and to exit the tab.
Apply Click to save the changes made to this tab and to stay in the current tab.
Additional changes can be made and the Apply button pressed when
making changes incrementally.
Close Click to exit the current tab. If changes have been made but not
committed by clicking the Apply button, a dialog box displays.
Reset Click to reset the tab to the last set of committed changes. If the Apply
button has not been pressed on this tab, the parameters are returned to
the original values the tab had when it was initially displayed.
