3-36 Web Tools User’s Guide
Fabric View
3
Quick Loop
Use the Quick Loop tab to create and manage Quick Loops. For information on managing the
Quick Loop feature separately, see Loop Tab in this document. The Quick Loop tab is shown in
Figure 3-20.
Figure 3-20 Quick Loop tab of the AL_PA Level Zoning menu
Add Mem Click to add a member from the member selection list into the Zone
Members list.
Remove Mem Click to remove a member from the Zone Member List when selected.
Ref Zone Click to refresh the local zoning data base copied from the switch.
This button automatically flashes red/gray if the fabric zoning data is
changed by another client.
A/D WWN Click to add or delete a WWN to or from all the aliases, zones defined
Rpl WWN Click to replace WWN with another one in all aliases, zones defined.
OK Click to apply the changes to the switch and exit the switch.
Apply Click to apply the changes to the switch.
Close Click to exit the window without making any changes to the switch.
Clr All Click to clear all aliases, zones, configs locally on the switch.
