Run pitch
Sets the pitch of the line sewing.
Range: 1 - 10 mm (0.04 - 0.39 inch)
Default: 2 mm (0.08 inch)
Run times
Sets the number of times the border will be sewn.
Range: 1 - 5
Default: 1
Motif Stitch only:
Pattern
Select a pattern for Motif sewing.
Click
Select Pattern , and the Browse dialog will display. Select
the folder containing the pmf file you want to open. Scroll
through the available stitch patterns and double-click the
desired pattern or click
OK to select the pattern
Pattern Size
Width
Sets the pattern width (the direction along the line).
Range: 2 - 10 mm (0.08 - 0.39 inch)
Default: 5 mm (0.20 inch)
Height
Sets the pattern height (the direction perpendicular to the line).
Range: 2 - 10 mm (0.08 - 0.39 inch)
Default: 5 mm (0.20 inch)
H-Arrange
(Horizontal Arrange)
Sets the horizontal arrangement of the
pattern. For patterns like , patterns will
be arranged along the line as shown to the
right.
V-Arrange
(Vertical Arrange)
Sets the vertical arrangement of the pat-
tern. For patterns like , patterns will be
arranged along the line as shown to the
right.
Region sewing attribute
Setting items according to the selected stitch
Satin stitch
Region sewing
Under sewing
Density
Direction
Pull compensation
Fill stitch
Region sewing
Under sewing
Density
Direction
Pull compensation
Step pitch
Frequency
Programmable fill
Region sewing
Under sewing
Density
Direction
Pull compensation
Programmable Fill
Pattern
Pattern size
Width
Height
Offset
Direction
Value
Direction
Motif stitch
Region sewing
Motif
Use pattern
Pattern1
Pattern
Pattern size
Width
Height
H-Arrange
V-Arrange
Pattern2
Pattern
Pattern size
Width
Height
H-Arrange
V-Arrange
Offset
Direction
Run pitch
Normal:
Mirror:
Alternate:
Normal:
Mirror:
Alternate:
