3.4
ANALOG REMOTE MODE PROGRAMMING
The BOP can be programmed remotely using analog signals applied to the remote Analog I/O
port at the rear panel (see Figure 2-1 and Table 2-10). Analog remote programming allows the
user to 1) establish voltage or current mode (PAR. 3.4.2), 2) control the main channel using the
BOP as a power amplifier (PAR. 3.4.3) and 3) establish the protection limits (PAR. 3.4.4). An
output signal proportional to output current is also provided for external use (PAR. 3.4.5).
3.4.1
REMOTE OUTPUT OFF
There are two ways two turn off the output using remote signals: (1) Remote Shutdown which
requires the unit to be turned off, then on in order to restore operation and (2) Remote Standby
which sets the output to OFF, putting the unit in STANDBY status.
Series or Parallel when not
STANDALONE
Mismatch between Unit type and Connection type. Automatically reverts to
Unit type: Standalone, Connection Type: standalone.
Calibration invalid - Multiple Unit
Consult Factory.
BITBUS option must be Disabled
Change CIIL mode to SCPI. From power-up screen press
%
highlight Interface Data For-
mat, press
!
, highlight SCPI, press
$
, then press
$
to save for power-up, then
cycle BOP off, then on.
Waveform Menu
External Reference Waveform not
accessible
Reference Input must be set to Internal for waveforms to be executed. Press
$
highlight
Reference Input, press
!
highlight Internal, press
$
, then
%
.
External Mode - Waveform not
accessible
External Mode must be disabled for waveforms to be executed. Press
$
highlight Exter-
nal Mode, press
!
highlight Disable, press
$
, then
%
.
External Limits - Waveform not
accessible
Protection Limit must be set to Internal for waveforms to be executed. Press
$
highlight
Protection Limit, press
!
highlight Internal, press
$
, then
%
.
Empty Entry - use F2 instead
Empty location cannot be modified using
!
Press
@
to start new waveform.
No Room to insert - delete a segment. No more than 10 segments are allowed in a waveform.
Unable to delete segment.
Try again. If still unable to delete segment, contact factory. for RMA.
Only EDIT allowed on Entry.
When viewing waveform, if name, count or protection levels are highlighted, press
!
to
modify the setting.
@
and
!
are not functional with these parameters.
MODE incorrect - Please Change
A voltage waveform was executed while the unit was in current mode or a current
waveform was executed while the unit was in voltage mode. Press MODE key to change to
correct mode, press STANDBY key to set output on then press
$
to run the waveform
Unit in STANDBY - Please Change
Output must be on for the waveform to be executed. press STANDBY key to set output on
then press
$
to run the waveform
Can not delete Single Segment - use
F1 to Change
Waveform must have at least one segment.
Can not delete the empty segment.
“End of Segments” was highlighted when
#
- Erase was pressed. Move highlight to valid
segment and try again.
Entry not Empty, Use F1 to change.
@
pressed while a previously saved waveform was highlighted. Use
!
to modify or
highlight Empty and press
@
for a new waveform.
Under Minimum allowed value
Frequency or period was too small.
Frequency has no sign
+/- key is not functional when modifying frequency.
Use F5 to stop waveform.
$
not valid when waveform already executing.
TABLE 3-13. ERROR MESSAGE EXPLANATIONS (CONTINUED)
ERROR MESSAGE
EXPLANATION
