BOP HIPWR 022108
1-7
FUNCTION GENERATOR CHARACTERISTICS (Continued)
Amplitude Resolution (Programming)
Main Channel and Offset Voltage (millivolts a-c) .35 Sine
(millivolts d-c) 1 Triangle, Square, ±Ramp, Level:
Current (milliamperes a-c) .35 Sine
(millivolts d-c) 1 Triangle, Square, ±Ramp, Level:
Protection Limit Channel . Current, bipolar
(Amperes)
0.1
Voltage, bipolar
(Volts)
0.1
Amplitude Accuracy
Main Channel and Offset Voltage 0.03% EO
NOM
Current 0.1% IO
NOM
Protection Limit Channel . Current 0.5% IO
NOM
Voltage 0.3% EO
NOM
Distortion (THD-F, Total Harmonic Distortion rela-
tive to the fundamental component) 5% max. Sine
13% max. Triangle
70% max. ±Ramp
47% max. Square
Start/Stop Angle (Phase) Range 0 to 360° Sine, Triangle
Programming Resolution 0.1°
Accuracy Start Angle 1°
Stop Angle 1° @ 0.01Hz, to 16° @ 443 Hz Frequency dependent
SAVE/RECALL CHARACTERISTICS (See PAR. 3.3.8)
Number of Locations 99
Parameters Saved or Recalled All parameters saved for power-up.
Mode of operation Voltage, Current or External For External the operating mode is deter-
mined by signal at I/O Port; no signal selects
voltage mode (see PAR. 3.4.2).
Reference type Internal, External or
External Reference Level
Main channel
Internal, External or
Lesser Limit
Limit channel
Main Amplitude
(Internal)
0 to EO
NOM
or IO
NOM
(internal or external)
Main Channel:
Voltage (Volts) for Voltage mode,
Current (Amperes) for Current mode
Protection Limit Amplitude
(Internal)
EO
MIN
or IO
MIN
to
1.01 EO
NOM
or IO
NOM
Limit Channel, Positive and Negative
Voltage (Volts) for Current mode,
Current (Amperes) for Voltage mode
Output status ON or OFF
TABLE 1-2. BOP GENERAL SPECIFICATIONS (Continued)
SPECIFICATION RATING/DESCRIPTION CONDITION
