3-26
BOP HIPWR 022108
Note that a single segment between 0.01Hz and 1.8Hz uses all available points, so subsequent
segments will not be accepted. Four segments of 2.81Hz will be acceptable, while five seg-
ments at 2.81 Hz will not be accepted. Reducing the segment by using the start and stop angle
will also reduce the number of points used.
Each time a segment is added, the waveform is validated. When a segment is added that
causes the point total to exceed 3933, three asterisks *** will appear to the left of the segment,
and the error message “LIST TOO SMALL” will be displayed briefly. This can be corrected by
either reducing the number of segments, or increasing the frequency of the existing segments
until the point total is acceptable.
3.3.9.4 WAVEFORM SPECIFICATIONS
Refer to Table 1-2 for specifications applicable to waveforms created either locally, using the
BOP front panel (Local) or remotely from a host computer, using LIST commands (Remote). Dif-
ferences between local and remote operation are highlighted.
TABLE 3-9. SINE, TRIANGLE AND RAMP WAVEFORM FREQUENCY VS. POINTS
Frequency
(See Notes 1, 2, and 3) Total Points
Frequency
(See Notes 1, 2, and 3) Total Points
From To From To
0.01Hz 2.7Hz 3840 55.5Hz 66.5Hz 160
2.71Hz 3.6Hz 2880 66.6Hz 88.7Hz 120
3.71Hz 5.5Hz 1920 88.8Hz 118.3Hz 90
5.6Hz 8.3Hz 1280 118.4Hz 147.9Hz 72
8.4Hz 11.0Hz 960 148Hz 177.4Hz 60
11.1Hz 14.7Hz 720 177.5Hz 221.8Hz 48
14.8Hz 22.1Hz 480 221.9Hz 295.8Hz 36
22.2Hz 33.2Hz 320 295.81Hz 354.9Hz 30
33.3Hz 44.3Hz 240 355.9Hz 443.7Hz 24 (See Note 2)
44.4Hz 55.4Hz 192 443.8z 532Hz 20 (See Note 3)
NOTES: 1. As the frequency varies within the range, the time interval per point varies proportionately.
2. Sine and Triangle segments can not exceed 443Hz.
3. Ramp segments can not exceed 532Hz.
TABLE 3-10. SQUARE WAVEFORM FREQUENCY VS. POINTS
Frequency
(See Note 1) Total Points
Frequency
(See Notes 1) Total Points
From To From To
0.02Hz 1.8Hz 3840 43.51Hz 58.0Hz 120
1.81Hz 2.7Hz 2880 58.01Hz 72.5Hz 90
2.71Hz 4.0Hz 1920 72.51Hz 87.0Hz 72
4.01 5.4Hz 1280 87.01Hz 108.7Hz 60
5.41 7.2Hz 960 108.71Hz 145.0Hz 48
7.21Hz 10.8Hz 720 145.2.9Hz 174.0Hz 36
10.81 16.3Hz 480 174.1Hz 217.5Hz 30
