BOP HIPWR 022108

3-33

3.3.9.10 COPYING A WAVEFORM

After observing the precautions of PAR. 3.3.9.1, press

@

from the power-up screen to enter

the Saved Waveforms screen (Figure 3-9). Highlight one of the stored waveforms, then press

$

. Then highlight a waveform location designated

Empty

and press

$

to save or

%

to abort

the change and exit. The copied waveform may then be modified and saved with a new name if
desired (see PAR. 3.3.9.7).

3.3.10

RESET

CAUTION: PRESSING RESET WILL CAUSE VOLTAGE TRANSIENTS TO APPEAR AT

THE OUTPUT WHICH MAY DAMAGE A CONNECTED LOAD. SWITCH IS
RECESSED TO PREVENT INADVERTENT ACTIVATION.

Pressing

RESET

causes the power supply to execute a complete power on sequence to reset

the power supply to the power up settings (see PAR. 3.3.7).

3.3.11

OPERATOR TESTING

The Test System submenu is entered by pressing

%

from the power-up screen, then highlight

Revison/Test and press

!

. Upon power-up all tests are flagged as

Untested

. Table 3-14 lists

the tests that can be run. Highlight the choice and press

#

to run the selected test.

3.3.12

ERROR MESSAGE EXPLANATIONS

When a key press is not accepted, an error message is displayed at the bottom of the screen.
Although recovery from most operator errors is obvious and simple, Table 3-13 lists all the error
messages along with associated explanations as to why they occurred.

TABLE 3-13. ERROR MESSAGE EXPLANATIONS

ERROR MESSAGE

EXPLANATION

General

Multiple Decimal places not supported Decimal key was pressed while to the right of the existing decimal point.

Exceeding Maximum Allowed Value

To check maximums, go to power-up screen, press

%

, highlight Max/Min Settings, press

!

.

Sign does not affect Protection Limits

Protection Limit field is positive or negative, numerical value does not need sign

Entry incomplete, Depress ENTER
key

When changing either the main channel or the protect channel, using the number keys, the
change must be applied to the output by pressing ENTER before moving on to change the
other channel.

Executing List

A waveform is currently executing via remote mode. Commands to change the output are
not accepted until list is stopped (send command VOLT:MODE FIXED).

Save Disabled, Request ignored

Save Display Change is disabled. From power-up screen, press

%

, highlight password

settings to enable.

EXTERNAL MODE enabled.

MODE key does not function while Mode is being controlled externally. Press

$

, high-

light External Mode and change to Disable.

F2 Key not valid

F2 only works when labeled. key was probably pressed inadvertently.

Password incorrect

Enter the correct password and press

!

. If password has been lost and can not be

recovered, refer to PAR. 3.6.3.12.1 to reset to factory defaults.

Setup Menu

F3 - Invalid

#

only works when labeled. Key was probably press inadvertently.

F4 - Invalid

$

only works when labeled. Key was probably press inadvertently.

Master/Slave Menu
