1-2

BOP HIPWR 022108

TABLE 1-2. BOP GENERAL SPECIFICATIONS

SPECIFICATION

RATING/DESCRIPTION

CONDITION

INPUT CHARACTERISTICS

a-c voltage

nominal

230 Va-c

Single phase

range

176 - 264 Va-c

Frequency

nominal

50-60 Hz

>65 Hz, leakage
exceeds spec

range

47 - 65 Hz

Current 176

Va-c

9.5A

maximum

264 Va-c

6.4A

maximum

Power factor

Source

0.99 minimum

nominal output power

Sink

0.97 minimum

Efficiency

65%

minimum

Switching frequency

70 KHz

PFC Stage

EMC Compliance

EN61326-1 (1997)

Class A equipment

EMC immunity to:

ESD

EN61000-4-2

Electrostatic discharge

Radiated RF

EN61000-4-3

EFT

EN61000-4-4

Electrical fast transient/burst

Surges

EN61000-4-5

Conducted RF

EN61000-4-6

EMC emissions

Conducted

EN61000-3-2

harmonics

EN61000-3-3

fluctuation & flicker

Conducted

EN55011/CISPR11

0.15 to 30 MHz

Radiated

EN55011/CISPR11

30 to 1000 MHz

Leakage current

3.5 mA

230V a-c, 47-63 Hz

Insulation coordination

Input

Installation Category II

Overvoltage Category II

Output

Installation Category II

Overvoltage Category II

Pollution degree

2

OUTPUT CHARACTERISTICS

1

Type of stabilizer

Voltage-current, 4-quadrant

Switch mode

Switching frequency

100KHz

Output Stage

Source adjustment range

voltage

-100% to +100% of rating

0 to 50 deg C

current

-100% to +100% of rating

Sink adjustment range

voltage

-100% to +100% of rating

Recuperated energy is sent
back into line for reuse

current

-100% to +100% of rating

Programming
resolution / accuracy

Voltage

14 bits / 0.03%

2% accuracy for Ext Ref Level (see PAR.
3.4.3.2). Unit gain adjustable between 0 and
EO

NOM

(voltage) or EO

NOM

(current).

Current

14 bits / 0.1%

Voltage Limit

12 bits / 0.3%

Current Limit

12 bits / 0.5%

Readback
resolution / accuracy

Voltage

16 bits / 0.05%

main or limit channel

Current

16 bits / 0.1%

main or limit channel

NOTE 1 - Output characteristics are for a single standalone unit. Output characteristics of identical multiple unit parallel/series configura-

tions are described in the Technical Manual associated with the applicable Cable Kit (see Table 1-5).
