Average

Multiple data is averaged to form a
waveform. This mode is useful for
drawing a noise-free waveform. To
select the number, press Average
repeatedly.
Average number: 2, 4, 8, 16, 32, 64, 128,
256

Peak detect

To activate the Peak detect mode,
press Peak-Detect. Only the minimum
and maximum value pairs for each
acquisition interval (bucket) are used.
This mode is useful for catching
abnormal glitches in a signal.

Peak detect effect
using the probe
comp. waveform

1. One of the probe

compensation waveforms
can demonstrate the peak
detection mode. Connect the
probe to the probe
compensation output.

2. Press the Utility key.

Utility

3. Press ProbeComp.

4. Press Wave Type and select

the

waveform.

5. Press the Autoset key. The

oscilloscope positions the
waveform in the center of
the display.

Autoset

6. Press the Acquire key.

Acquire
