background image

PRINT

117

P

RINT

The GDS-1000A is able to print screen images
directly to a PictBridge compatible printer. The
printed images can use the “Ink Saver” feature to
print onto a white rather than a black background
to reduce the amount of ink used. Note that
printing and remote control cannot be used at the
same time.

Print (Hardcopy)

Background

The Hardcopy key works as a
shortcut for printing screen
images directly to a printer or
to save display images,
waveform data, and panel
settings onto an SD card.

Hardcopy

The Hardcopy key can be configured into three
types of operations: save image, save all (image,
waveform, setup) and printer.

USB connection Printer end

Type A, host

GDS-1000A end

Type B, slave

Speed

1.1/2.0 (full speed)

Procedure

1. Connect the USB cable to

the USB slave port on the
GDS-1000A rear panel.
