Trigger key 1/6, Trigger key 2/6 – GW Instek GDS-1000A Series User Manual User Manual

Page 35

QUICK

REFERENCE

Trigger key 1/6

Type

Edge

Source

CH1

Mode

Auto

Slope /

Coupling

Holdoff

40.0ns

Set to

Minimum

Trigger Type

Trigger Holdoff

Select Trigger type or Trigger
Holdoff menu

Type

Trigger key 2/6

Select video trigger type

Type

Select trigger source

Source

Select video standard

Standard

Select video polarity

Polarity

Select video field/line

Line

→VAR
