GDS-1000A Series User Manual
130
Probe Specifications
GDS-1062A/1102A/1152A Probe
Applicable model &
probe GDS-1062A
GTP-060A-4*
GDS-1102A
GTP-100A-4*
Position x 10 Attenuation Ratio 10:1
Bandwidth DC ~ 60MHz DC ~ 100MHz
Input Resistance 10MΩ when used with 1MΩ input
Input Capacitance 23pF approx. 17pF approx.
Maximum Input
Voltage 500V CAT I, 300V CAT II (DC+Peak AC)
Derating with frequency
Position x 1 Attenuation Ratio 1:1
Bandwidth DC ~ 6MHz
Input Resistance 1MΩ when used with 1MΩ input
Input Capacitance 128pF approx. 47pF approx.
Maximum Input
Voltage 300V CAT I, 150V CAT II (DC+Peak AC)
Derating with frequency
Operating Cond. Temperature –10°C ~ 55°C
Relative Humidity ≤85% @35°C
Safety Standard EN 61010-031 CAT II
Applicable model &
probe GDS-1152A GTP-150A-2*
Position x 10 Attenuation Ratio 10:1
Bandwidth DC ~ 150MHz
Input Resistance 10MΩ when used with 1MΩ input
Input Capacitance 17pF approx.
Maximum Input
Voltage 500V CAT I, 300V CAT II (DC+Peak AC)
Derating with frequency
Position x 1 Attenuation Ratio 1:1
Bandwidth DC ~ 6MHz
Input Resistance 1MΩ when used with 1MΩ input
Input Capacitance 47pF approx.
Maximum Input
Voltage 300V CAT I, 150V CAT II (DC+Peak AC)
Derating with frequency
Operating Cond. Temperature –10°C ~ 55°C
Relative Humidity ≤85% @35°C
Safety Standard EN 61010-031 CAT II
* Note: GW Instek reserves the right to change the probe model type (GTP-060A-4,
GTP-100A-4, GTP-150A-2) at anytime without notice for probe model types of similar
specification.
