GDS-1000A Series User Manual
6
Saving the display image ................................................... 106
Saving all (panel settings, display image, waveform) ....... 108
Recall .............................................................................. 110
File type/source/destination.............................................. 110
Recalling the default panel settings ................................... 111
Recalling a reference waveform to the display .................. 112
Recalling panel settings ..................................................... 112
Recalling a waveform ......................................................... 113
Recall Image ....................................................................... 115
P RINT .......................................................... 117
Print (Hardcopy) ............................................................. 117
M AINTENANCE ........................................... 120
Vertical Resolution Calibration ........................................ 120
Probe Compensation ....................................................... 121
F AQ .............................................................. 123
The input signal does not appear in the display. .............. 123
I want to remove some contents from the display. .......... 123
The waveform does not update (frozen). .......................... 124
The probe waveform is distorted. ...................................... 124
Autoset does not catch the signal well. ............................. 124
I want to clean up the cluttered panel settings. ................ 124
The saved display image is too dark on the background. . 124
The accuracy does not match the specifications. ............. 125
The SD card slot does not accept my card. ....................... 125
The oscilloscope will not allow a 2M waveform to be saved.
............................................................................................ 125
A PPENDIX .................................................... 126
Fuse Replacement ........................................................... 126
GDS-1000A Series Specifications ..................................... 127
Model-specific specifications ............................................ 127
Common specifications ..................................................... 128
Probe Specifications ........................................................ 130
GDS-1062A/1102A/1152A Probe ...................................... 130
EC Declaration of Conformity .......................................... 131
I NDEX .......................................................... 132
