SAVE/RECALL

101

Quick Save (HardCopy)

Background

The Hardcopy key works as a
shortcut for printing screen
images directly to a printer or
to save display images,
waveform data, and panel
settings onto an SD card.

Hardcopy

The Hardcopy key can be configured into three
types of operations: save image, save all (image,
waveform, setup) and printer.

Using the Save/Recall key can
also save files with more
options. For details, see
page103.

Save/Recall

Functionalities Save


(*.bmp)

Saves the current display image into
an SD card.

Save

all

Saves the following items into an SD
card.

Current display image (*.bmp)

Current system settings (*.set)

Current waveform data (*.csv)

SD Card
restriction

The GDS-1000A series accepts the following SD
cards:
Type: SD, SDHC
Class: 2,4,6
Size: Up to 32GB (SDHC)
Format: FAT or FAT32

Procedure

1. Insert an SD card to the slot.

2. Press the Utility key.

Utility

3. Press Hardcopy Menu.
