7. pArAMETEr dESCrIpTION
7-9
IM 01R04B04-00E-E 8th edition March 01, 2011 -00
All Rights Reserved. Copyright © 2003, Rota Yokogawa
parameter
data
form
data range
dec.
point
Unit
r : read
W : write
Exe :
execute
reset
Master
reset
power on
default
Temperature format
Select
xxxxxxx
-
-
R/W
X
xxxxxx.X
xxxxx.X
xxxx.XX
xxx.XXX
xx.XXXX
x.XXXXX
Temperature LRV
Decimal
Standard: -200 to 230°C 0 to 5
Temperature unit
R/W
X
-200
High Temp.: 0 to 400°C
Temperature URV
Decimal
Standard: -200 to 230°C 0 to 5
Temperature unit
R/W
X
230
High Temp.: 0 to 400°C
Temperature damping
Decimal
0 to 200
1
Sec.
R/W
X
3
Temp alm 1 sel
Select
No function
-
-
R/W
X
No function
More than
Less than
Temp alm 1 crit
Decimal
Standard: -200 to 200°C 0 to 5
Temperature unit
R/W
X
LRV
Temp alm 2 sel
Select
No function
-
-
R/W
X
No function
More than
Less than
Temp alm 2 crit
Decimal
Standard: -200 to 230°C 0 to 5
Temperature unit
R/W
X
URV
High Temp.: 0 to 400°C
Temp fix val select
Select
Inhibit
-
-
R/W
X
X
Inhibit
Enable
Temp fixed val
Decimal
Standard: -200 to 230°C 1
Temperature unit
R/W
X
X
30
High Temp.: 0 to 400°C
Temp gain
Decimal
0.8 to 1.2
3
-
R/W
1
Velocity unit
Select
m/s
-
-
R/W
X
m/s
ft/s
Analog 1 select
Select
Mass flow
-
-
R/W
X
Mass flow
Volume flow
Density
Temperature
Concentration meas
Net flow
None
Analog 1 alarm out
Select
<2.4mA
-
-
R/W
X
<3.6mA
<3.6mA
4.0mA
>21mA
>21.6mA
Hold
Measured Value
Analog 1 low LMT
Decimal
NAMUR:3.8 to 20.5 mA 2
mA
R/W
X
3.8 (Namur);
Not NAMUR:2.4 to
21.6 mA
2.4 (not
Namur)
Analog 1 high LMT
Decimal
NAMUR:3.8 to 20.5 mA 2
mA
R/W
X
20.5 (Namur);
Not NAMUR:2.4 to
21.6 mA
21.6 (not
Namur)
