5. BASIC OpErATINg prOCEdUrES
5-3
IM 01R04B04-00E-E 8th edition March 01, 2011 -00 All Rights Reserved. Copyright © 2003, Rota Yokogawa
In the title indication the following abbreviations are used :
MASS FLOW RATE : MFR Additional with option /Cx :
VOLUME FLOW RATE : VFR CONCENTRATION : CON
FORWARD MASS TOTAL : FTM NET FLOW : NET
REVERSE MASS TOTAL : RTM FORWARD NET TOTAL : FTN
DIFFERENTIAL MASS TOTAL : DTM REVERSE NET TOTAL : RTN
FORWARD VOLUME TOTAL : FTV DIFFERENTIAL NET TOTAL : DTN
REVERSE VOLUME TOTAL : RTV
DIFFERENTIAL VOLUME TOTAL : DTV
DENSITY : DEN
TEMPERATURE : TMP
FORWARD ENERGY TOTAL : FTE
VELOCITY : VEL
FORWARD TOTAL FLEX : FTL FORWARD TOTAL FLEX : FTL
REVERSE TOTAL FLEX : RTL
DIFFERENTIAL TOTAL FLEX : DTL
DRIVE GAIN : DGN
Number of figures :
totalizer ≤ 999999 : 1 sign + 6 figures (e.g. +123456)
totalizer ≤ 9999999 : 1 sign + 7 figures (e.g. +1234567)
totalizer > 9999999 : Exponential view (e.g. +1.23E12)
measured value : 7 figures + 1 sign (e.g. +1234567) or
6 figures + 1 sign + 1 decimal point (e.g. +123.456)
unit : 10 figures
title : 3 figures
The contrast of the display can be adjusted with parameter
Detailed setup / Display Config / Disp contrast
The indication period of the display can be adjusted with parameter
Detailed setup / Display Config / Disp period
5.2 display modes
The display can show the following indication modes :
1 Measuring mode Actual selected measuring values are shown
2 Parameter setting mode
2a Entry mode A confirmation, that setting via the infrared buttons should really happen
2b Parameter search mode Mode to search the parameter, which should be changed
2c Parameter select mode Mode to rewrite data. There are 4 types of data :
- Select type (not blinking)
- Numerical type (blinking)
- Numerical type with sign (blinking)
- Character type (blinking)
2d Data confirmation mode Mode to confirm new value of selected parameter
2e Data determination mode Parameter setting is completed
3 Alarm mode Alarm or Error Code is displayed alternating with measuring mode
(2s Alarm / 4s Measure). Warnings are not displayed. Access to
Warnings via Self Test/Status.
In measuring mode the actual measured values according the display select parameters are indicated as
shown in chapter 5.1. How to set display settings see chapter 5.4.
Parameter setting mode is described in chapter 5.3.
The language of the parameter setting mode can be selected in parameter
Language / or Detailed setup / Display config / language .
English, German, French or Russian can be selected.
