11. TECHNICAl dATA
11-16 IM 01R04B04-00E-E 8th edition March 01, 2011 -00 All Rights Reserved. Copyright © 2003, Rota Yokogawa
Integral type rCCT3, Option- Code (continued) :
Options Option
code description restrictions
High Driving Power /HP High Driving Power not for RCCT34, recommended for RCCT36
to 39, strongly recommended for RCCT39/IR,
mandatory for RCCT39/XR
Fieldbus Communication /FB Digital communication Foundation Fieldbus protocol (refer to GS 01R04B05-00E)
Active Pulse Output /AP One active pulse output not with /KF2, /EF2, /UF2, /NM
NAMUR Switch /NM One pulse output acc. to EN 60947-5-6 (NAMUR) not with /AP
Analog Alarm Levels /NA Analog output alarm levels 2.4 mA or 21.6 mA
(Standard is acc. to NAMUR rec. 43)
Tag Number /BG With customer specified tag number on name plate max. 16 digits
HART Tag Number (Software Tag) /BT1 With customer specified tag number for HART communication in converter 8 digits for tag, 22 digits for long tag
Flange Facing /DN
/RJ Flange with safety grooves acc. to EN 1092-1 form D
Ring Type Joint Flanges only for D2 to D6; not HC
only for A3, A4, A5; not HC
Gas Measurement /GA Gas measurement, special factory adjustments and settings to be conform with ANSI/ISA-12.27.01 select /RD
Special Calibration /K2 2)
/K4
/K5
2)
/K6
Custom 5 pts mass-/volume-flow calibration using water with factory certificate
(traceable to German national standards)
Density adjustment + thermal treatment; (accuracy: 0.001 g/cm³)
Custom 10 pts mass-/volume-flow calibration using water with DKD certificate
(according EN-17025:2005)
Density calibration with 3 different fluids incl. individual temperature compensation
with certificate (accuracy: 0.0005 g/cm³)
only RCCT34 to 39; not with /GA
only RCCT34 to 39; not with /GA
Certificates /P2
/P3
/P6
/P8
/H1
/WP Certificate of compliance with the order acc. to EN 1024:2004 -2.1
As /P2 + Test report acc. to EN 1024: 2004 -2.2 (QIC)
Material certificate acc. to EN 1024: 2004 -3.1
Pressure test report measuring system
Oil and fat free for wetted surface acc. to ASTM G93-03 level C
WPS acc. DIN EN ISO 15609-1 (Welding Procedure Specification)
WPQR acc. DIN EN ISO 15614-1 (Welder Performance Qualification Record)
WQC acc. DIN EN 287-1 (Welder Qualification Certificate)
only for butt weld between process connection
and flow divider; not for material HC
Sanitary Type /SF1
/SF2
/SA
/SE
Surface roughness Ra = 0.8 µm
As /SF1 + Test report roughness of wetted parts
As /SF2 + 3A- declaration of conformity and 3A- mark
As /SF2 + EHEDG certificate
not RCCT39/XR; only process connections S2,
S4, S8; see also restrictions in table 11-10
not with process connection S2
not with process connection S2
Customer Presetting /PS Presetting sheet with customer data has to be issued with the order
Housing Pressure Test /J1 Rupture pressure proof test and certificate:
60 bar (RCCT34, RCCT36), 40 bar (RCCT38), 10 bar (RCCT39, RCCT39/IR) not for RCCT39/XR
X-Ray Examination /RT X-ray examination of flange welding RCCT34 with /K4 or /K6 only one-sided
PMI Examination /PM6 PAMI test (6 test points: process connection inlet + outlet, measuring tubes, flow
divider inlet + outlet)
3)
Dye Penetration Test /PT Dye penetration test of flange welding
Epoxy Coating /X1 Epoxy coating of converter housing
Concentration Measurement 4) /CST
/Cxx Standard concentration measurement
Advanced concentration measurement, details see table „Advanced Concentration
Measurement Options“
Delivery to Japan /PJ For meters which are delivered to Japan, with SI-unit preset
Adapter /AD2 2 pcs ANSI 1/2“ NPT / G1/2 adapter pcs ANSI 1/2“ NPT / G1/2 adapter ANSI 1/2“ NPT / G1/2 adapter only with cable conduit ´A´
Instruction Manuals /IEn
/IDn
/IFn Quantity of instruction manuals in English
Quantity of instruction manuals in German
Quantity of instruction manuals in French n = 1 to 3 selectable 5)
n = 1 to 3 selectable 5)
n = 1 to 3 selectable 5)
Quick Delivery /QD Delivery within 24 hours from factory not RCCT39/IR, RCCT39/XR,
not with process connection size 23, 12,
only with process connection rating A1, A2, D4,
only material SL,
only for options /KF1, /FF1, /EF1, /UF1, /HP, /AP,
/NM, /NA, /BG, /P2, /P3, /P8, /CST, /Cxx, /IEn,
/IDN , /IFn
Special order /Z Special design must be specification an extra sheet
2) Calibration order sheet must be delivered with the order. This is available on the Flow Center Page at Coriolis/RCCx3/Technical Information.
3) Measuring tube PAMI test is performed per delivery batch.
4) For detailed information please see TI 01R04B04-04E-E. Concentration measurement is recommended with option /K6.
5) If no instruction manual is selected, only a CD with instruction manuals is shipped with the instrument. More than 3 manuals of one language on request.
