11. TECHNICAl dATA
11-20 IM 01R04B04-00E-E 8th edition March 01, 2011 -00 All Rights Reserved. Copyright © 2003, Rota Yokogawa
remote cable rCCY03, Model-, Suffix- and Option- Code :
Model Suffix Code Option
Code description restrictions
RCCY031
RCCY032
RCCY033
RCCY034 Length in ´meter´
Length in ´feet´
Length in ´meter´
Length in ´feet´ max. ambient temperature 70°C; with /FFx or /FS1: 50°C
max. ambient temperature 70°C; with /FFx or /FS1: 50°C
max. ambient temperature 105°C; with /FFx or /FS1: 85°C
max. ambient temperature 105°C; with /FFx or /FS1: 85°C
Cable ends -0
-1 No termination, with one termination kit
Terminated
Cable length Lxxx Enter the length max. 300m / 999ft (with /FFx or /FS1 max. 50m / 165ft);
the following lengths can be ordered (e.g. 3m = L003):
RCCY031-0: 3m, 5m, 10m, 15m, 30m, 50m, 100m, 150m, 200m, 250m, 300m
RCCY031-1: 3m, 5m, 10m, 15m, 30m, 50m
RCCY032-0: 10ft, 15ft, 30ft, 50ft, 100ft, 150ft, 300ft, 500ft, 1000ft
RCCY032-1: 10ft, 15ft, 30ft, 50ft, 100ft, 150ft
RCCY033-0: 3m, 5m, 10m, 15m, 30m, 50m, 100m, 150m, 300m
RCCY033-1: 3m, 5m, 10m, 15m, 30m, 50m
RCCY034-0: 10ft, 15ft, 30ft, 50ft, 100ft, 150ft, 300ft, 500ft, 1000ft
RCCY034-1: 10ft, 15ft, 30ft, 50ft, 100ft, 150ft
Options:
Hazardous area installation
Termination kits
Quick delivery
/KS1
/TKxx
/QD Blue cable for Ex-i indication
Quantity of additional termination kits
Delivery within 24 hours from factory
xx = 01 to 99
only RCCY031-1, L003, L005, L010
remote rack-mount converter rCCr31, Model-, Suffix- and Option- Code :
Model Suffix Code Option
Code description restrictions
RCCR31 Remote converter for 19´´ rack mounting to be connected to RCCS3
Power supply -A
-D 90 - 264 V AC
24 V DC
Hazardous Area Approvals 1) /KS1
/FS1
/ES1
/US1 ATEX associated apparatus for intrinsic safe detector connection for gas group IIC
FM associated apparatus for intrinsic safe detector output
IECEx associated apparatus for intrinsic safe detector output for gas group IIC
INMETRO associated apparatus for intrinsic safe detector output for gas group IIC with /HP for gas group IIB
with /HP not for gas groups A and B
with /HP for gas group IIB
with /HP for gas group IIB
GOST Approval 1) /QR1 Russian GOST approval see chapter 9.5
High Driving Power /HP High Driving Power not for combination with RCCS30 to 34, recom-
mended for combination with RCCS36 to 39,
strongly recommended for combination with
RCCS39/IR, mandatory for combination with
RCCS39/XR
Active Pulse Output /AP One active pulse output not with /NM
NAMUR Switch /NM One pulse output acc. EN 60947-5-6 (NAMUR) not with /AP
Analog Alarm Levels /NA Analog output alarm levels 2.4 mA or 21.6 mA
(Standard is acc. NAMUR rec. 43)
Tag Number /BG With customer specified tag number on name plate max. 16 digits
HART Tag Number (Software Tag) /BT1 With customer specified tag number for HART communication in converter 8 digits for tag, 22 digits for long tag
Gas Measurement /GA Gas measurement, special factory adjustments and settings select affiliated RCCS3 with /GA
Combination with RCCS39/XR /XR Special converter adjustment with RCCS39/XR mandatory for combination with RCCS39/XR
No Combination /NC No combination with detector
Customer Presetting /PS Presetting sheet with customer data has to be issued with the order
Concentration Measurement 2) /CST
/Cxx Standard concentration measurement
Advanced concentration measurement, details see table „Advanced Concentration
Measurement Options“
Subrack /SR1
/SR2 Subrack for 2 converter RCCR31 with mounting
Subrack for 4 converter RCCR31 with mounting
Instruction Manuals /IEn
/IDn
/IFn Quantity of instruction manuals in English
Quantity of instruction manuals in German
Quantity of instruction manuals in French n = 1 to 3 selectable 3)
n = 1 to 3 selectable 3)
n = 1 to 3 selectable 3)
Special order /Z Special design must be specification an extra sheet
1) Select affiliated RCCS3 with the same approval type (e.g. /KS1 with /KS1).
2) For detailed information please see TI 01R04B04-04E-E. Option /K6 of RCCS3 is recommended with concentration measurement.
3) If no instruction manual is selected, only a CD with instruction manuals is shipped with the instrument. More than 3 manuals of one language on request.
