4. INSTAllATION
4-20 IM 01R04B04-00E-E 8th edition March 01, 2011 -00 All Rights Reserved. Copyright © 2003, Rota Yokogawa
1VMTFSBUF ：∼)[（L)[）
-PBE
*GUIFMPBESFTJTUBODFJTLų
77WPMUBHFQVMTFJTPCUBJOFE
305"."44
1PVU
1PVU
'BJ
&MFDUSPOJDDPVOUFS
7™
Lų
4. Pulse Output active (option /AP)
Pulse output 1 (Pout) can be ordered as active output. Not possible with intrinsic safe outputs option /KF2.
5. Status Output active (option /AP)
Status output 1 (Pout) can be ordered as active output. Not possible with intrinsic safe outputs option /KF2.
Magnetic
valve
ROTAMASS
Pout +
Load
ROTAMASS
Pout -
Pout +
Pout -
F421.EPS
12V, 6mA max., Load > 10kΩ
12V, 6mA max.
+
+
