<6. Operation of FlowNavigator Program> 6-17
IM 01C25R51-01E
6.3.2 Import
(1) Import Flow Configuration .XMV file.
“User Flow Parameters” and “Device Flow Parameters” for EJX Multivariable Transmitter
can be imported.
(2) Import Flow Configuration *.VMV file
“User Flow Parameters” and “Device Flow Parameters” for digitalYEWFLO Vortex
Flowmeter can be imported.
NOTE
Refer to ‘9.1 Configuration File’ for information of file format of Flow Configuration file.
Import can be used in the Flow Configuration Mode screen.
NOTE
The XMV file made on the FSA210 is compatible with FSA120.
Figure 6.16a Importing a File
NOTE
Flow Configuration Wizard R1.02.01 or later does not allow setting the gauge pressure to the
Reference pressure. If importing .XMV file in which the Reference pressure is configured as the
gauge pressure using R1.02.00 or earlier, the following message is displayed.
Figure 6.16b Information Message for Reference Pressure
Reenter the absolute pressure equivalent to the displayed gauge pressure for the Reference
Condition in Fluid Operating Range Setup screen.
