<8. Operation of DYFMVTool> 8-9
IM 01C25R51-01E
Input mole component of 21 materials.
Range must be checked as Table 8.6.
Total mole percent must become 100%.
• Standardize: Standardize the mole component value.
Click [Standardize] button when total mole percent does not become 100%.
• Reset: Reset the mole component value
• Total mole: Total mole percent is displayed
NOTE
In case that “Total Mole” is displayed as “100%”, error message is displayed as follows.
“The total mole should exactly be 100%”
Click [Standardize] button.
Table 8.6 ISO12213 Mole Valid Range
#
Component Mole Valid Range (Expanded Range)
1 CH4 Methane mole percent 50–100 %
2 N2 Nitrogen mole percent 0–50 %
3 CO2 Carbon Dioxide mole percent 0–30 %
4 C2H6 Ethane mole percent 0–20 %
5 C3H8 Propane mole percent 0–5 %
6 H2O Water mole percent 0–0.015 %
7 H2S Hydrogen Sulfide mole percent 0–0.02 %
8 H2 Hydrogen mole percent 0–10 %
9 CO Carbon Monoxide mole percent 0–3 %
10 O2 Oxygen mole percent 0–0.02 %
11 C4H10 i-Butane mole percent 0–1.5 % *1
12 C4H10 n-Butane mole percent 0–1.5 % *1
13 C5H12 i-Pentane mole percent 0–0.5 % *2
14 C5H12 n-Pentane mole percent 0–0.5 % *2
15 C6H14 n-Hexane mole percent 0–0.1 %
16 C7H16 n-Heptane mole percent 0–0.05 %
17 C8H18 n-Octane mole percent 0–0.05 %
18 C9H20 n-Nonane mole percent 0–0.05 %
19 C10H22 n-Decane mole percent 0–0.05 %
20 He Helium mole percent 0–0.5 %
21 Ar ARGON 0–0.02 %
*1: ISOBUTANE (C4H10) and n-BUTANE (C4H10)’s sum cannot exceed 6 %.
*2: ISOPENTANE (C5H12) and n-Pentane (C5H12)’s sum cannot exceed 4 %.
