<5. Operational Flowchart> 5-8
IM 01C25R51-01E
(B) Configuration with existing configuration file (dns file)
Step FieldMate Menu
DYF(SoftDL) F OUNDATION fieldbus DTM
Layer1 Layer2 Layer3
DYFMVTool
Main Window
Procedure
"Online Parameter" is opened.
Load the *.dns file 2)
- "User Flow Parameters"
- "Device Flow Parameters"
- "Device General Parameters"
Edit "Device General Parameters"
and Apply to "Offline Database".
Confirm the compensation
calculation by input simulation for
flow rate, temperature and
pressure.
Download "Device Flow
Parameters" and "Device General
Parameters".
Goes offline.
1 Start DTM
Open "DNS"
file and
download
parameters to
the device
Confirm flow
configuration
2
3
File
Assigned DTM
Device
Load from
file...
Parameter
Download to
device 1)
Online
Parameter
Disconnect
Device
F0506E.ai
1) Executing ‘Download to device’ will write both “Device Flow Parameters” and “Device General Parameters” into the
device. Before executing ‘Download to device’, execute ‘Upload from device’, so as to make General Parameters of the
device in the offline database synchronized with the device.
*: User Flow Parameters consist of fluid information and operating condition.
2) Temperature unit and pressure unit in AR Block are not configured in Flow Configuration Wizard Detail Compensation
Mode.
These parameters must be set manually in AR Block offline parameter.
