<5. Operational Flowchart> 5-9
IM 01C25R51-01E
(C) Configuration with existing configuration File (VMV file)
Step FieldMate Menu
DYF(SoftDL) F OUNDATION fieldbus DTM
Layer1 Layer2 Layer3
DYFMVTool
Main Window
Procedure
"Online Parameter" is opened.
Upload "Device Flow Parameters"
and "Device General Parameters".
Edit "Device General Parameters"
and Apply "Offline Database". 3)
"Import VMV Menu"
Import "User Flow Parameters"
and "Device Flow Parameters"
from existing file (*.vmv file).
Confirm / Modify compensation
mode and "Device Flow
Parameters".
Confirm / Modify "User Flow
Parameters".
Confirm / Modify "User Flow
Parameters".
Confirm / Modify "User Flow
Parameters" and "Device Flow
Parameters".
"Export -> Export VMV Menu"
Export "User Flow Parameters"
and "Device Flow Parameters" to
binary file.
Download
"Device Flow Parameters" and
"Device General Parameters".
Confirm the compensation
calculation by input simulation for
flow rate temperature and pressure.
"Report Menu"
Export "User Flow Parameters" in
CSV file format.
Apply "Device Flow Parameters"
to "Offline Database".
Goes offline.
1
Start DTM and
upload
parameter
from the
device
Import
existing
file and
confirm /
modify flow
configuration
Download
parameter to
the device
Confirm flow
configuration
2
3
4
Device
Device
Parameter Offline
Parameter
Flow
Configuration
Wizard
Flow
Configuration
Mode
Fluid Type
Setup
Fluid
Operating
Range Setup
Fluid Physical
Property
Setup
Apply Flow
Configuration
Assigned DTM
Device
Download to
device 2)
Upload from
device 1)
Parameter
Additional
Functions
Online
Parameter
Disconnect
Device
F0507E.ai
1) Before starting operation, execute ‘Upload from device’, so that “Device General Parameters” of the flowmeter in
the offline database are synchronized with the device. Upload data from the device does not include “User Flow
Parameters”.
*: “User Flow Parameters” consist of fluid information and operating condition.
2) Executing ‘Download to device’ will write both “Device Flow Parameters” and “Device General Parameters” into
the device. Before executing ‘Download to device’, execute ‘Upload from device’, so as to make “Device General
Parameters” of the device in the offline database synchronized with the device.
Download data to the device does not include “User Flow Parameters”.
3) Temperature unit and pressure unit in AR Block are not configured in Flow Configuration Wizard Detail Compensation
Mode.
These parameters must be set manually in AR Block offline parameter.
