<6. Operation of FlowNavigator Program>
6-11
IM 01C25R51-01E
(2) How to download to a device
• HART DTM
1. Click the [Device] → [Parameter] → [Offline Parameter]
2. Click the [Device] → [Download to Device]
.
•.F
OUNDATION
fieldbus DTM
1. Click the [Device] → [Parameter] → [Offline Parameter]
2. Check the checkbox of the function blocks downloading to a device.
Figure 6.10a Checkbox of Blocks to Download (EJX910 F
OUNDATION
fieldbus DTM)
Figure 6.10b Checkbox of Blocks to Download (DYF(SoftDL) F
OUNDATION
fieldbus DTM)
IMPORTANT
• It is recommended to select all blocks.
• Following block must be checked to download “Device Flow Parameters” set by Flow
Configuration Wizard.
EJX910 F
OUNDATION
fieldbus DTM: Download FTB Block
DYF(SoftDL) F
OUNDATION
fieldbus DTM: Download AR Block
