<5. Operational Flowchart> 5-10
IM 01C25R51-01E
5.3 Flow Parameters Download Procedure
The basic procedure for downloading the flow parameters to a device is as follows. Refer to
Figure 5.2.
Step 1 Upload from Device
Perform “Upload from Device” so that the setting parameters (“Device Flow Parameters” and
“Device General Parameters”) in the device are saved to the offline database on your PC.
The parameters will then be displayed in the Offline Parameter screen.
Step 2 Flow Configuration
Perform Flow configuration in accordance with the guidance in the Flow Configuration Wizard.
“Device Flow Parameters” are output by Flow Configuration Wizard.
Save “Device Flow Parameters” as XMV file (EJXMVTool) or VMV file (DYFMVTool) in the last
menu, and click the “Apply” button.
“Device Flow Parameters” are then stored to the offline database on your PC.
NOTE
Clicking on Apply does not download the flow parameters to the device.
