<7. Operation of EJXMVTool> 7-10
IM 01C25R51-01E
Input the value as mole percent for each component shown in Table 7.9.
The each value must be specified within the range shown in Table 7.9.
Total mole percent must become 100%.
• Standardize: Standardize the mole component value.
Click [Standardize] button when total mol percent does not become 100%.
• Reset: Reset the mole component value
• Total mole: Total mole percent is displayed
NOTE
In case that “Total Mole” is displayed as “100%”, error message is displayed as follows.
“The total mole should exactly be 100%”
Click [Standardize] button.
Table 7.9 ISO12213 Mole Valid Range
#
Component Mole Valid Range (Expanded Range)
1 CH4 Methane mole percent 50–100 %
2 N2 Nitrogen mole percent 0–50 %
3 CO2 Carbon Dioxide mole percent 0–30 %
4 C2H6 Ethane mole percent 0–20 %
5 C3H8 Propane mole percent 0–5 %
6 H2O Water mole percent 0–0.015 %
7 H2S Hydrogen Sulfide mole percent 0–0.02 %
8 H2 Hydrogen mole percent 0–10 %
9 CO Carbon Monoxide mole percent 0–3 %
10 O2 Oxygen mole percent 0–0.02 %
11 C4H10 i-Butane mole percent 0–1.5 % *1
12 C4H10 n-Butane mole percent 0–1.5 % *1
13 C5H12 i-Pentane mole percent 0–0.5 % *2
14 C5H12 n-Pentane mole percent 0–0.5 % *2
15 C6H14 n-Hexane mole percent 0–0.1 %
16 C7H16 n-Heptane mole percent 0–0.05 %
17 C8H18 n-Octane mole percent 0–0.05 %
18 C9H20 n-Nonane mole percent 0–0.05 %
19 C10H22 n-Decane mole percent 0–0.05 %
20 He Helium mole percent 0–0.5 %
21 Ar ARGON 0–0.02 %
*1: ISOBUTANE (C4H10) and n-BUTANE (C4H10) ‘s sum cannot exceed 1.5 %.
*2: ISOPENTANE (C5H12) and n-Pentane (C5H12) ‘s sum cannot exceed 0.5 %.
