8 . 1 2
■
I n s t a l l a t i o n a n d W i r i n g
Wa t l o w S e r i e s F 4 P
Communications Wiring
Figure 8.12a —
EIA/TIA 485 and EIA/TIA 232 Communications
Figure 8.12b —
Termination for EIA-232 to EIA-485 Converter
If the system does not work properly, it may need termination resistors at each
end of the network. A typical installation would require a 120-ohm resistor
across the transmit/receive terminals (12 and 13) of the last controller in the
network and the converter box or serial card. Pull-up and pull-down 1k ohm
resistors may be needed on the first unit to maintain the correct voltage during
the idle state.
Figure 8.12c —
EIA/TIA-232 Connections
• • • • • • • • • • • • •
1 2 3 4 5 6 7 8 9 10 11 12 13
14 15 16 17 18 19 20 21 22 23 24 25
• • • • • • • • • • • •
• • • • •
1 2 3 4 5
6 7 8 9
• • • •
14 16 15
14 16 15
Wire
F4
DB 9
DB25
Color
232
Connector Connector
White
TX Pin 14
RX Pin 2
RX Pin 3
Red
RX Pin 15
TX Pin 3
TX Pin 2
Black
GND Pin 16
Gnd Pin 5
GND Pin 7
Green
GND Pin 24
N/U Pin 9
N/U Pin 22
