8 . 2 ■ I n s t a l l a t i o n a n d W i r i n g Wa t l o w S e r i e s F 4 P
Figure 8.2a — Side and Top View and Dimensions.
Panel Dimensions
Figure 8.2b — Multiple Panel Cutout Dimensions.
Main Page___________
Go to Operations
Go to Setup
Go to Factory
Panel Cutout
Panel
Thickness
9.5 mm maximum
(0.375 in)
17.6 mm
(0.675 in)
minimum
16 mm
(0.625 in)
minimum
99.8 mm
(3.930 in)
F 4
1
2
1B 1B
1A 1A
ˆ
92 to 93 mm
(3.62 to 3.65 in)
å
99.8 mm
(3.930 in)
92 to 93 mm
(3.62 to 3.65 in)
