Wa t l o w S e r i e s F 4 P P a r a m e t e r s ■ 6 . 2 9
✔ Note: For more information about how parameter settings
affect the controller’s operation, see the Features Chapter. *The tenth digit of your model number, F4PX-XXXX-X X XX ,
determines what RTD calibration resistance values the unit
uses. Refer to the Ordering Information in the Appendix.
Options 1-4, 100 Ω RTD - 15.00 and 380.00
Ω
Options 5-8, 500 Ω or 1000 Ω RTD - 240.00 and 6080.00
Ω
Factory Page Parameter Table
Modbus
Register
Range read/write Conditions for
Parameter Description (Modbus Value) Default (I/O, Set) Parameters to Appear
Active: Always.
Inputs 2 and 3 appear only if the
controller is the enhanced ver-
sion (F4P _ - _ _ AB - _ _ _ _).
1603 [1]
1608
[2]
1613 [3]
r/w
Yes (7) 380.0 Ohms*
Store 380.00
Ω
calibration
for input RTD.
Active: Always. Input
1603 [1]
1608 [2]
1613 [3]
w
Yes (6) 240.0 Ohms*
Store 240.00
Ω
calibration
for the 500
Ω
or 1k
Ω
RTD
input.
Active: Always.
Inputs 2 and 3 appear only if the
controller is the enhanced ver-
sion (F4P _ - _ _ AB - _ _ _ _).
1603 [1]
1608
[2]
1613 [3]
r/w
Yes (6)
15.0 Ohms*
Store 15.00
Ω
calibration
for input RTD.
Active: Always.
Inputs 2 and 3 appear only if the
controller is the enhanced ver-
sion (F4P _ - _ _ AB - _ _ _ _).
1603 [1]
1608
[2]
1613 [3]
r/w
Yes (5) Lead
Store calibration for lead
resistance.
Active: Always.
Inputs 2 and 3 appear only if the
controller is the enhanced ver-
sion (F4P _ - _ _ AB - _ _ _ _).
1603 [1]
1608
[2]
1613 [3]
r/w
Yes (4) Ground
Store calibration for
ground at gains of 1 and
32.
Active: Always.
Inputs 2 and 3 appear only if the
controller is the enhanced ver-
sion (F4P _ - _ _ AB - _ _ _ _).
1603 [1]
1608
[2]
1613 [3]
r/w
Yes (3) 32°F Type J
Store 32°F type J calibra-
tion.
Active: Always.
Inputs 2 and 3 appear only if the
controller is the enhanced ver-
sion (F4P _ - _ _ AB - _ _ _ _).
1603 [1]
1608
[2]
1613 [3]
r/w
Yes (2) 50.00mV Thermocouple
Store 50.000mV calibra-
tion for input thermocou-
ple.
Active: Always.
Inputs 2 and 3 appear only if the
controller is the enhanced ver-
sion (F4P _ - _ _ AB - _ _ _ _).
1603 [1]
1608
[2]
1613 [3]
r/w
Yes (1)
0.00mV Thermocouple
Store 0.000mV calibra-
tion for input thermocou-
ple.
Main Page > Factory > Calibration > Calibrate Input x (1 to 3)
Calibrate Input x (1 to 3)
Active: Always. 1602 r Yes (800) Full Defaults
Causes all parameter
values to revert to their
factory default settings.
Active: Always. 1513 w (1) Display Test
Checks LED display seg-
ments by turning them
on and off.
