A . 1 4 ■ A p p e n d i x Wa t l o w S e r i e s F 4 P
Setup Page
see Chapter 4
System
PID Units
°F or °C
Show °F or °C
Maximum Transfer Heat
Maximum Transfer Cool
Manual to Auto Transfer
Autotune Set Point
Failure Mode
Input 1 Fail
Open Loop Detect
Analog Input x (1 to 3)
Sensor
Type
Analog Input 2
Control Type
Analog Input x (1 to 3) continued
Units
Decimal
Scale Low
Scale High
Scaling
Set Point Low Limit
Set Point High Limit
Offset Type
Calibration Offset Value
Clear Input x (1 to 3) Offsets
Offset Point x (1 to 10)
Offset Value x (1 to 10)
Filter Time
Error Latch
Square Root
Analog Input 3
Auto/Manual Slidewire Calibration
Slidewire Learn Closed
Slidewire Learn Open
Slidewire Deadband
Slidewire Hysteresis
Control Type
Cascade
Cascade Low Range, Process
Cascade High Range, Process
Cascade Low Deviation Range
Cascade High Deviation Range
Digital Input x (1 to 4)
Function
Name
Activate Message
Message Display Time
Condition
Control Output x (1A, 1B)
Function
Cycle Time Type
Cycle Time Value
Process
Duplex (1A)
High Power Limit
Low Power Limit
Boost Type (1B)
Boost Power Mode (1B)
Boost Set Point Type (1B)
Alarm Output x (1 and 2)
Name
Alarm Type
Alarm Source
Latching
Silencing
Alarm Hysteresis
Alarm Sides
Alarm Logic
Alarm Messages
Retransmit Output x (1 and 2)
Retransmit Source
Analog Range
Low Scale
High Scale
Scale Offset
Communications
Baud Rate
Address
Custom Main Page
Parameter x (1 to 16)
Process Display
Display Time
LED Intensity
Static Message
Message x (1 to 4)
Factory Page
see Chapter 5
Set Lockout
Set Point
Oper. Autotune PID
Oper. Edit PID
Oper. Alarm SP
Setup Page
Factory Page
Set/Change Password
Clear Locks
Oper. PID Crossover
Oper. Ramp Set Point
Oper. Control Set Point
Oper. Remote/Local Set Point
Diagnostic
Model
Mfg Date
Serial #
Software #
Revision
In x (1 to 3)
Out x (1A or 1B)
Retrans x (1 or 2)
In x (1 to 3) A to D
CJC (1 to 3) A to D
CJC (1 to 3) Temp
Line Freq
Test
Test Outputs
Display Test
Full Defaults
Calibration
Calibrate Input x (1 to 3)
Calibrate Output x (1A or 1B)
Calibrate Rexmit x (1 or 2)
Restore In x (1 to 3) Cal
