Wa t l o w S e r i e s F 4 P F a c t o r y P a g e ■ 5 . 1
Chapter Five: Factory Page
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.1
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.3
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.3
5
Security
The Series F4P allows users to set separate security
levels for the Static Set Point prompt on the Main Page,
for all menus on the Operations Page, as well as for the
Setup Page and Factory Page. Four levels of security are
available:
• Full Access (operators can enter and change
settings);
• Read Only (operators can read but not change
settings);
• Password (operators can enter and change settings
after entering a password); and
• Hidden (operators cannot see the menu or page — it
is not displayed). Set Point settings cannot be
Hidden.
✔ Note: Full Access is the default for all menus. Unless
you change the level of access, operators will be able to
read and change every setting in every menu in the
Series F4P software.
How to Set Lockout Levels
Using the Lockout Menu, you can limit access to the
following menus and pages:
• Set Point on Main Page
• Operations Page Autotune PID
• Operations Page Edit PID
• Operations Page Alarm Set Point
• Setup Page
• Factory Page
Choose the item to lock out, press .. and choose the level
of access: Full, Read Only, Password or Hidden. If you
choose Password, you must set the password — see
below.
✔ Note: For more information about how parameter
settings affect the controller’s operation, see the Features
Chapter.
ç CAUTION: Only authorized and qualified personnel
should be allowed to perform preventive and corrective
maintenance on this unit.
…Lock>Autotune PID___
Full Access
Read Only
>Password
.
…Factory>Set Lock___
Set Point
>Oper. Autotune PID ■
Oper. Edit PID ▼
.
Main>Factory________
>Set Lockout
Diagnostic
Test
