Wa t l o w S e r i e s F 4 P A p p e n d i x ■ A . 3
Ordering Information
(2330)
1/4 DIN Single-Channel Controller
Series F4P F4 P - A -
Single-Channel
temperature/process controller,
1 universal analog input, 2 alarms,
EIA-232/485 communications,
4 events/digital inputs
Power Supply
H = 100-240V
ı (ac/dc)
Output 1A
C = Open collector/switched dc
E = Electromechanical relay,
Form C, 2A without
contact suppression
K = Solid-state Form A 0.5A relay
without contact suppression
F = Process, 0-5, 1-5, 0-10V Î (dc),
0-20mA, 4-20mA
Output 1B
A = None
C = Open collector/switched dc
E = Electromechanical relay,
Form C, 2A without
contact suppression
K = Solid-state Form A 0.5A relay
without contact suppression
F = Process, 0-5, 1-5, 0-10V Î (dc)
0-20mA, 4-20mA
Control Operation
A = Standard Control Operation
B = Enhanced Control Operation,
dual universal inputs, cascade,
ratio, differential, slidewire control
Auxiliary Retransmit Module
0 = None
1 = Single retransmit output 0-5, 1-5, 0-10V
Î (dc),
0-20mA, 4-20mA
2 = Dual retransmit outputs 0-5, 1-5, 0-10V Î (dc),
0-20mA, 4-20mA
Language Option
1 = English - 100 RTD
2 = German - 100 RTD
3 = French - 100 RTD
4 = Spanish - 100 RTD
5 = English - 500 & 1000 RTD
6 = German - 500 & 1000 RTD
7 = French - 500 & 1000 RTD
8 = Spanish - 500 & 1000 RTD
Display and Custom Options
RG = Standard Red Upper LED/Green Lower LCD only
XX = Custom options: software, setting parameters, overlays
