37

4. Operation Using I/O Signals

4.2 Standard

Type

Choose the PIO pattern of this type if you wish to perform position control using pulse train input from a PLC.
Set User Parameter No. 25 (PIO pattern selection) to “0.” (This parameter has been set to the “standard type” prior to
the shipment).

4.2.1

Explanation of I/O Signals

Pin No.

Signal

Name

Remarks

1

24 V

External 24 V

2

0 V

External ground

If the controller is used in the open collector mode, also use this pin for the
COMMON signal for command pulses as well as the 0V signal for the
controller’s control power.

3 IN0

SON

Servo-on

signal

4

IN1

TL

Torque-limit selection signal

5 IN2

HOME

Homing

signal

6 IN3

RES

Reset

signal

7 OUT0 SV

Servo-on

output

8

OUT1

INP

Positioning complete signal

9

OUT2

HEND

Homing complete signal

10 OUT3 *ALM

Alarm

signal

11 /PP

Command

pulse

12

PP

Command pulse

Not connected if the controller is used in the open collector mode.

13 /NP

Command

pulse

14

NP

Command pulse

Not connected if the controller is used in the open collector mode.

„ Servo-on Command Input (SON)

The servo remains on while this signal is ON.
The actuator can be operated while the SON signal is ON.
While this signal is OFF, the actuator does not operate even when the controller power is supplied.
If the SON signal is turned OFF while the actuator is operating, the actuator will decelerate at the forced-stop torque
until it stops. After the actuator stops, the servo will turn off and the motor will enter a free-run state.
At this time, the function specified by the applicable parameter (electromagnetic brake) becomes active (provided
that the actuator is equipped with a brake).
When the servo turns off, the deviation counter will be cleared if User Parameter No. 58 (Clear deviation at servo
off/alarm stop) is set to “Enable.”

„ Reset Signal Input (RES)

This signal resets the alarms currently detected by the controller.
You can turn the RES signal ON to reset the alarms currently detected by the controller.

Caution:

This signal cannot reset cold-start level alarms. Identify the cause of each alarm and remove the cause
before restarting the controller.
