1. Specifications Check
23
1. Specifications Check
1.1 Checking the Product
The standard configuration of this product is comprised of the following parts.
See the component list for the details of the enclosed components. If you find any fault or missing parts, contact
your local IAI distributor.
1.1.1
Parts
No.
Name
Model number
Quantity
Remarks
1 Actuator
Refer to “How to Read the Model
Nameplate” and “How to Read the
Model Number.”
1
Accessories
2 Motor • encoder cables
(Note1)
1 set
3 Nut
Refer to list below
4 First Step Guide
1
5 Operation Manual (DVD)
1
6 Safety Guide
1
Note1 The motor • encoder cables differ between the standard model and robot cable.
[Refer to 1.4, Motor • Encoder Cables.]
[List of Included Nut Type]
Model No.
Nut
M10u1.25
Nut
M12u1.25
Nut
M14u1.5
Nut
M20u1.5
Nut
M22u1.5
Square Nut
6u6 M4
Square Nut
7u7 M4
Square Nut
10u10 M6
RCS2-RA7AD
1
RCS2-RA7BD
1
RCS2-SRA7BD
1
RCS2-RA5C
4 or 8*1
RCS2-RA5R
1
4 or 8*1
RCS2-RGD5C
4 or 8*1
*1
Stroke 100mm or less: 4 pieces, stroke more than 100mm: 8 pieces
Model No.
Nut A
M26u1.5
Nut B
M35u1.5
Nut C
M8u1.5
Nut A
M30u1.5
Nut B
M40u1.5
Nut C
M10u1.5
RCS2-RA4C
1
1
1
RCS2-RA4D
1
1
1
RCS2-RA4R
2
1
RCS2-RGS4C
1
1
RCS2-RGS4D
1
1
