Tempest®24 00 2 -Channel Wireless Intercom System
No audio passing when not using an external hardwired intercom system and Tempest BaseStati ons are
sharing intercom channels.
•
Confi rm that no wired intercoms are connected to the system.
•
Confi rm a 3-pin XLR cable connecti on for each channel to be shared, between each of the BaseStati ons.
•
Set the BaseStati on 2-Wire Intercom Type Select Switch to the Clear-Com positi on.
•
Select 2-Wire for the relevant channels. Set only
one
of the Tempest BaseStati ons to Master Mode.
No audio passing when using an external hardwired intercom system and Tempest BaseStati ons are
sharing intercom channels.
•
Confi rm a 3-pin XLR cable connecti on for each channel to be shared, between each of the BaseStati ons.
•
Set the BaseStati on 2-Wire Intercom Type Select Switch to the appropriate positi on.
•
Select 2-Wire for the relevant channels.
•
For each channel to be shared, connect the wired intercom to one of the BaseStati ons.
Audio can only be passed from one BaseStati on to another in the “Clear-Com mode”
unless actually connected to to another type of wired intercom system. Connecti ng
any wired intercom to any BaseStati on will automati cally disable Master Mode and
disconnect all shared channels that do not have a wired intercom connected.
When connecti ng any shared BaseStati ons to any wired intercom system, only
channels connected to the wired system can be shared.
