Clear-Com V12PDDXY - Manual (Page 169)

The available limiters are shown in display 3 and the limiter parameters and units are shown
in display 4.
The limiters are described below:
Options Description / comments
type Select a preset limiter from the range limit1 - limit6 shown in
display 4.
enable
Select yes or no in display 4 to enable/disable this limiter
decay Decay time in ms shown in display 4
attack Attack time in ms shown in display 4
knee Knee in dB shown in display 4
comp Compression shown in display 4
gain
Markup gain of limiter in dB shown in display 4
thresh The threshold below which the limiter has no effect shown in
display 4
Table 50: Limiters (display 3)
8.3.6 filter
The filter command allows the current filter to be displayed and changed.
Display 2 shows the input stream of the filter being accessed.
Display 3 shows the action.
Display 4 shows the action status.
Figure 197: filter display
169 V-Series Panels User Guide
