8635 - 53
O
PERATING AND
C
ONTROLLER
F
UNCTIONS
Procedure for specifying the basic settings
Configuration of the keys
NOTE The functions and factory settings shown in grey are optionally valid with analog
repeat
(OUTPUT) or with process controller (P.CONTRL).
➔ On first commissioning of the SIDE Control, make the following basic settings:
• Enter the control function of the actuator used.
• Start the automatic adaptation of the controller to the current operating conditions
( AUTOTUNE).
Commissioning and set-up as a positioner
➔ Before commissioning, execute the fluidic and electrical installations.
Factory settings of the controller (S/HART)
Function Factory setting
CHARACT CHA LIN
CUTOFF CUT = 0 % ; CUT = 100 %
DIR.CMD DIR.CRISE
DIR.ACT DIR.ARISE
SPLTRNG SR = 0 (%); SR = 100 (%)
X.LIMIT LIM = 0 %, LIM = 100 %
X.TIME
T.OPN Values determined by AUTOTUNE
T.CLS Values determined by AUTOTUNE
After execution of SETFACT: 1 s
OUTPUT
OUT ANL:
OUT POS OUT 4'20 A
OUT BIN :
OUT DEV DEV 5.0 NORM OPN
SAFEPOS 0
BIN-IN B.IN SPOS / NORM OPN
Function Factory setting
X.CONTRL
X.CO DBND 1 %
X.CO PARA
KX Values determined by AUTOTUNE
KX Values determined by AUTOTUNE
After execution of SETFACT: 1
P.CONTRL
P.CO DBND 1 %
P.CO PARA
KP 1.00
TN 999.9
TV 0.0
X0 0
P.CO SETP SETP INT
P.CO FILT 0
P.CO SCAL PV 000.0, PV 100.0
P.CO TUNE D’ACT
CODE CODE 0000
MANUAL/AUTOMATIC Switch between main and sub-menu
key items, e.g. ADDFUNCT - CHARACT
Arrow keys Switch between equal-ranking menu
items, e.g.
ADDFUNCT - X.TUNE
