Burkert Type 8635 - Manual (Page 114)

112 - 8635
C
ONFIGURATION FOR
B
US
C
OMMUNICATION
(PROFIBUS PA)
Module = "SP+READBACK+POS_D+CHECKBACK"
0xC7,0x84,0x89,0x08,0x05,0x08,0x05,0x05,0x05,0x0A
EndModule
Module = "RCAS_IN+RCAS_OUT" 0xC4,0x84,0x84,0x08,0x05,0x08,0x05
EndModule
Module = "RCAS_IN+RCAS_OUT+CHECKBACK" 0xC5,0x84,0x87,0x08,0x05,0x08,0x05,0x0A
EndModule
Module = "SP+RB+RIN+ROUT+POS_D+CB"
0xCB,0x89,0x8E,0x08,0x05,0x08,0x05,0x08,0x05,0x08,0x05,0x05,0x05,0x0A
EndModule
Slave_Family = 12
;************** Additional Keywords For Modul Assignment *****************
;*************** Slave Related Keywords For DP Extensions ***************
;************* Slave Related Keywords For ProfiSafe Profile ***************
END OF GSD FILE
(5.)
(6.)
(7.)
(4.)
One option is to be selected from the options for cyclic data exchange.
Under (1.) is to be found the simplest possibility, which corresponds only to the setpoint.
If one wishes to work with this manufacturer-specific file, the ident number selector must be set to
„Manufacturer-Specific“ (1).
