8635 - 35
S
YSTEM
D
ESCRIPTION
(PROFIBUS PA)
OPERATING CONDITIONS
Permissible ambient - 25 ... + 65 °C (with non-Ex devices or T4/T5)
temperature - 25 ... + 60 °C (with T6)
System of protection IP 65 to EN 60529
(only with correctly connected cable)
CONFORMITY TO THE FOLLOWING STANDARDS
CE symbol Conformity wrt. EMC Guideline 89/336/EEC
Low Voltage Guidline 73/23/EEC
Explosion protection (optional) EEX ia IIC T4/T5/T6
MECHANICAL DATA
Housing dimensions, outside (W x H x D) 174 x 88 x 93 mm
Housing material Aluminium
hard anodized and plastic-coated
Seal material NBR / Neoprene
Other exterior parts stainless steel (V4A)
Mass approx. 1.5 kg
ELECTRICAL DATA
Connections 2 M20 x 1.5
bushings with screw terminals 0.14 ... 1.5 mm 2
Power supply via PROFIBUS PA signal
to Ex segment coupler 9 ... 15 V DC (Ex)
to segment coupler 9 ... 24 V DC (NonEx)
Operating current from bus 12 mA ± 7 % without FDE
Fault current protection 5 mA ± 10 % FDE
Binary input mechanical make/break contact
Inductive proximity switch (optional) to DIN EN 60947-5-6 (NAMUR)
Structural shape SJ3,5-G-N
Manufacturer Pepperl+Fuchs
Output signal for
switching amplifier to DIN EN 50227 (NAMUR)
Rated voltage U
0
8 V
Current (sensor uncoated)
≥
2.1 mA
Current (sensor coated) ≤ 1.2 mA
Technical data of the SIDE Control (PROFIBUS PA)
Technical data (PROFIBUS PA)
