Chapter 6 Avaya P130 CLI
Avaya P130 User’s Guide 77
Set port channel Command
Use the set port channel command to enable or disable a Link Aggregation
Group (LAG) interface on the module. You can also add or remove a port from an
existing LAG. All ports in the LAG are configured with the base ports' parameters
such as port speed, duplex mode, VLAN ID, tagging mode, priority level. When
adding a port to an existing LAG, type the same LAG-name (or no LAG-name),
otherwise you will get an error message. The added port must belong to the same
connector group - refer to the "LAG" indication on device's front panel. When a port
is removed from a LAG, it becomes disabled.
The syntax for this command is:
set port channel / {on | off}
Example:
P130-1# set port channel 1/6,18 on server2
Port 1/6 channel mode set to on
Port 1/18 was added to channel
Set port redundancy enable/disable Command
Use the set port redundancy command to enable or disable the defined
redundancy schemes. Using this command will not delete existing redundancy
entries.
Note: You must disable Spanning Tree before you can enable redundancy.
The syntax for this command is:
set port redundancy {enable|disable}
Example:
P130-1# set port redundancy enable
All redundancy schemes are now enabled
Module number
A list of ports to be aggregated, separated by commas.
Name for the LAG interface.
