Chapter 4 Installation and Setup

28

Avaya P130 User’s Guide

5

Set the baud rate, ppp authentication, and ppp time out required to match your
modem. These commands are described in the “Command Line Interface”
chapter.

6

At the prompt, type:
set interface ppp enable

The CLI responds with the following:

Entering the Modem mode within 60 seconds...

Please check that the proprietary modem cable is plugged
into the console port

7

Use the DB-25 to RJ-45 connector to plug the console cable to the modem’s DB-
25 connector. Plug the other end of the cable RJ-45 connector to the
Avaya P130 console’s RJ-45 port.

8

The Avaya P130 enters modem mode.

9

You can now dial into the switch from a remote station, and open a Telnet
session to the PPP interface IP address.

Assigning P130’s IP Stack Address

Note:

All P130 switches are shipped with the same default IP address. You must

change the IP address of the master P130 switch in a stack in order to guarantee that
the stack has its own unique IP address in the network.

Use the CLI to assign the P130 stack/standalone switch an IP address and net mask.
The network management station can establish communications with the stack/
standalone switch once this address had been assigned and the stack/standalone
switch has been inserted into the network.
To assign a P130 IP stack/standalone switch address:
1

Establish a serial connection by connecting a terminal to the Master P130 switch
of the stack.

2

When prompted for a Login Name, enter the default name root

3

When you are prompted for a password, enter the password root. You are
now in Supervisor Level.

4

At the prompt, type:
set interface inband

Replace , and with the VLAN,
IP address and net mask of the stack.

5

Press Enter to save the IP address and net mask.

6

At the prompt, type reset and press Enter to reset the stack. After the Reset,
log in again as described above.

7

At the prompt, type set ip route and replace
and with the destination and gateway IP addresses.

Press Enter to save the destination and gateway IP addresses.
