88

017-882-B0-001 Rev. C2 (10/2013)

3.0

Operation

3.7 Automatic Performance Test

Automatic Self Test: An automatic Self Test is periodically performed to verify the state of the batteries

and the inverter circuitry. The automatic test feature has several programmable parameters that determine

the frequency and duration of automatic tests. A running test may be halted manually by pressing the TEST

button a second time.
The automatic test feature is on by default. To turn auto-test off, change Test Interval to 0 days in the POWER

CONFIG Menu. Auto-test may be enabled at any time by changing the test interval to any numerical value

(excluding “0”). The default test interval is 30 days.

The test sequence process:
• Begins with a check to verify the batteries are attached and the battery circuit breaker is closed. If the

batteries are discharged or not connected, the Power Supply does not attempt to operate in inverter

mode, preventing a drop of the load.

• Next, the Power Supply switches to standby mode for a pre-programmed period. Successful completion

of a test sequence indicates the unit is operating normally in standby mode, the battery voltage did not

drop below a preset threshold and the output was stable throughout the test. Failure of test is indicated

by a Self Test Fail alarm, which can be cleared by subsequently running a successful test for at least

one minute.

In addition to automatic testing, the operator can manually initiate a Self Test. A running test may be halted

at any time by pressing the Self Test switch on the front panel (below the OUTPUT and ALARM LEDS on

the Inverter Module) or from the PWR CONFIG menu. The status monitoring card allows a Self Test to be

initiated via the webpage as well.
Test Inhibit: The Test Inhibit command prevents an automatic test scheduled to occur in the next week. This

command is useful if periodic maintenance of the Power Supply is scheduled close to the next scheduled

automatic test.
Use this feature when inclement weather might cause a utility failure. The Test Inhibit command affects an

automatic test scheduled to run in the next seven days. Multiple issues of the Test Inhibit command result in

the deferral of the next automatic test until at least seven days after the last request. This command has no

effect if an automatic test is not scheduled to take place in the next week. Starting a test manually overrides

the Test Inhibit command.
